Facial Tissue Machine
2L/3L/4L/5L/6L/7L/10L
1. The rewinding and slitting machine rewind and slit single-layer large rolls of toilet paper into multi-layer paper rolls
2. The high-speed facial tissue machine processes paper rolls into facial tissue paper through embossing, folding, electronic counting, and cutting
2. The high-speed facial tissue machine processes paper rolls into facial tissue paper through embossing, folding, electronic counting, and cutting
Delivery
EXW,FOB,CFR,CIF
minimum order
1 set
Supply Ability
100set / Year
Country of Origin
China
Stock Time
20Day
Model
Quantity
US $3500.00 - US $30000.00
/ set
Introduction to facial tissue machine
Big roll paper → tissue rewinder cutter → facial tissue making machine→ (Multi-layer)
1.tissue rewinder cutter for facial tissue making machine
1.Tissue rewinder adopt air shaft to rewind to make the paper tube accurate positioning
2.Adop steel-to-steel blank holder and independent cylinder adjustment to achieve no layering on each layer of paper
3.Tissue rewinder adopt horizontal unwinder,pneumatic paper
4.Pneumatic wide leather moving paper feeding,each tissue rewinder has separate volume paper tension adjusting device
5.Tissue rewinder drag base paper with front and rear jog switch,simple and safe operation
Parameter of tissue rewinder for facial tissue making machine
| Model | 1575 | 1880 |
| Working speed | 180-300 m/min | |
| Maximun paper width | 2200 mm | |
| Maximun base paper diameter | 1300 mm | |
| Max roll diameter | 350 mm | |
| Power | 5.5 kw | |
2. Automatic facial tissue machine
After facial tissue machine folding, then put it into box. pull them out one by one during use.
Parameter of facial tissue making machine
| Model | 2L 3L 4L |
| Finished size | 200*200 mm |
| Base paper diameter | ≤ 1300mm diameter |
| Inner diameter of base paper core | 76.2mm |
| Speed | 0-180m/min |
| Embossing roller end | Felt roller,wool roller,rubber roller,steel roller |
| Blank lines | steel on steel, Independent regulation |
| Embossing device | steel to steel embossing |
| Power | 3kw |
| Cutting | Penumatic point cut |
| Vacuum system | 7.5kw |
| Pneumatic system | 3HP air compressor,pressure 5kg/cm2Pa |
Feature of facial tissue machine:
1. The roll width of facial tissue machine reaches 820mm and can produce 4 rows of tissue.
2. Facial tissue making machine adopts vacuum adsorption and automatic counting.
3. Facial tissue machine is equipped with tension adjustment device to ensure the dimensional accuracy of the finished product.
4. Facial tissue making machine comes with embossing function，making tissue more beautiful.
5. Max capacity of facial tissue machine can simultaneously produce 10 rows of tissue.
Finished production of facial tissue making machine
