High Density Pulp Cleaner
1/2/3/4/5/6/7/8
High consistency cleaner desander is a coarse impurity removal equipment in the pulp purification section, mainly suitable for pulp with a concentration range of 3% to 6%
Delivery
EXW,FOB,CFR,CIF
minimum order
1 set
Supply Ability
100set / Month
Country of Origin
china
Stock Time
20Day
Quantity
US $3000.00 - US $15000.00
/ set
High consistency centrifugal pulp cleaner desander removes heavy impurities such as sand particles and metal shavings from the pulp during the coarse purification process.
The core advantage of high consistency centrifugal pulp cleaner desander is that it can effectively intercept large particles and high hardness impurities, avoiding them from scratching pressure screens, grinders, etc; while the output of the pulper can directly enter High consistency centrifugal pulp cleaner desander without additional dilution, which can reduce water and energy consumption.
In practical applications, high consistency centrifugal pulp cleaner is often used in series with medium consistency centrifugal pulp cleaner and low consistency centrifugal pulp cleaner to construct a graded purification system of"coarse impurity removal fine impurity removal", ensuring the purity of final pulp.
Working principle of high consistency centrifugal pulp cleaner desander
The high consistency pulp enters along the tangent direction of centrifugal pulp cleaner desander cylinder under pressure, forming a high-speed rotating vortex. Heavy impurities such as sand particles, metal shavings, and stones are thrown towards the cylinder wall and gradually settle to the bottom for discharge,the purified fiber pulp flows upward along the central overflow pipe.
The high consistency pulp enters along the tangent direction of centrifugal pulp cleaner desander cylinder under pressure, forming a high-speed rotating vortex. Heavy impurities such as sand particles, metal shavings, and stones are thrown towards the cylinder wall and gradually settle to the bottom for discharge,the purified fiber pulp flows upward along the central overflow pipe.
Specification of high consistency centrifugal pulp cleaner desander
| Model | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 |
| Throught put(L/min) | 900 | 1300 | 1700 | 2400 | 3800 | 5500 | 7000 | 10000 |
| Consistency | 1.5%-5% | |||||||
| Inlet pressure | 0.2-0.4 MPa | |||||||
| Outlet pressure | 0.1-0.25 MPa | |||||||
| Wash water pressure | Inlet pressure +0.02 MPa | |||||||
